本反光對焊機是驅程輪輪輞電焊電焊的共用紫裝，其工件的的夾緊、電焊電焊均為液壓機式驅程，電焊電焊性能參數可由觸模屏設制，必備條件主動權化平均水平高、作業靠受得了、研究生調劑便利性等標志性。機用戶由監控主機、電子商務管理安全體系、液壓機式管理安全體系五部分帶來。The model of welder is the dedicated equipment for welding rim and disc. Its clamping and upsetting drive by hydraulic system, the welding parameters can be set from touch screen, and it features a high degree of automation, reliable operation, easy adjustable, etc. The welder is made of host, electrical system and hydraulic system.

活兒杭州特色

反光對焊機是輪子輪輞不銹鋼錫焊的通用設備，不銹鋼錫焊參數表由摸屏調節，積極化情況高、主線任務靠受得了、專業調劑便民等特點。有必要處理了高硬度板不銹鋼錫焊踏實及焊口硬度。自動化化：由交流伺服電機閥放肆閃頻燒化的應用程序，使電焊不改，渾然一體頻率快。面向尺寸差其他的輪輞，是可以挑選到渾然一體的電焊檔位。發展標有目的意義：達成無人值守化原產，插件活躍強弱料貸款機構，達成遙相呼應生活設施。

電標準

Electrical System

機械裝修標準帶有電焊焊接主集成運放系統和有節制集成運放系統。Electrical system includes welding main circuit and control circuit.(1)電弧對焊主電路系統由主啟閉QS、雙向可控硅啟閉KP和干式直流相電壓器TC3等定義。主啟閉QS使用來接聽電話和封控電弧對焊雙回路供電系統供電模塊，當專業調劑干式直流相電壓器級數或焊機牢固從不時，應掉線QS。雙向可控硅啟閉在焊機工作時使用來接聽電話或關斷電弧對焊供電模塊。干式直流相電壓器TC3使用來市場機制差別直流相電壓職位的電弧對焊直流相電壓，共8級。Welding main circuit is composed of the main switch QS, thyristor switch KP and transformer TC3. The main switch QS is used for switch-on and turn-off the power supply of welding circuit, it shall be turn off if adjust welding transformer series or long time on use. The thyristor switch KP is used for switch-on or turn-off the welding power when welder is running. The transformer TC3 is used for supplying different welding voltage which is total 8 series for this model.(2)規范三極管由PLC的傳輸精準度/傳輸精準度三極管、操控件、觸摸式式屏等產生。PLC是規范三極管的目光，焊機按PLC的英式重任，逆轉數字器經傘齒輪齒條與動板相接，應用在的檢測動板的位移，其精準度為35電智能/mm。PLC按電智能旌旗燈號規范動板的調速和控制回路，觸摸式式屏應用在監控功能焊機重任，并可按ajax請求點竄性能指標。Control circuit is composed of PLC input/output circuit, operation element and touch screen etc. The PLC is the core of control circuit, and the welder will run according to the programs of PLC. The rotary encoder is connected with movable plate through pinion and rack which is used to detect displacement of movable plate, with accuracy of 35pulse/mm. PLC will control the speed and reversing of movable plate according to the pulse signal. Touch screen is used to monitor welding operation, amend parameter in line with welding requirements.

液壓油缸體制

Hydraulic System

液壓多路閥多路閥油泵風險管理體系中由液壓多路閥多路閥油泵站、濾油器和虛擬設備上的油缸、閥等產生。液壓多路閥多路閥油泵站適用供應者風險管理體系中重壓。虛擬設備上的閥組適用合理各油缸的神器任務，此中頂鍛重壓、夾緊重壓、發動機預熱重壓都能夠零丁冶療，并有重壓表顯示冶療值，在頂鍛油缸裝有個杠桿比例冶療閥，適用冶療動板往前時的頻率。

、The hydraulic system is composed of hydraulic station, piping, oil cylinder and valve of host. Hydraulic station supplies the system pressure. The valves of host control the oil cylinders. The upsetting pressure, clamping pressure and pre-heating pressure can be adjusted separately which display the adjustment value by pressure gauge. And the upsetting oil cylinder is equipped with a lever regulating valve which is used for adjusting the forward speed of movable plate.

學手藝數劇

Specification

裝備型號	Model Number	UNB3-600-A
主電路額外輸出電壓 單相	Rated Input Voltage of Main Power Circuit	AC 400~430V, 50Hz, single phas
節制電路額外輸出電壓 三相	Rated Input Voltage of Control Power Circui	AC 380V, 50Hz, 3phas
主電路輸出電壓	Output Voltage of Main Power Circuit	8.8V～14.6V
電磁閥電壓(直流)	Voltage of Solenoid Valve	DC 24V
總輸出功率(千伏安)	Total Input Power	630KVA
最大頂鍛力	Maximum Upsetting Force	200KN
最大夾緊力	Maximum Clamping Force	550KN
最大焊接截面積	Maximum Welding Section Area	2800mm2
最大板寬	Maximum Width of Rim Band	320mm
最大板厚	Maximum Thickness of Steel Strip	4.5mm (up to 5.0mm)
最小焊接鋼圈直徑	Minimum Diameter of Rim Band	250mm
冷水機灌水量	Filling volume of cooling water machine	1300L
冷卻水溫度	Temperature of cooling water	≤ 25℃
